KING xr 9.8

retail price:
USD 350
More info
PRODUCT INFO
X-COBRA KING 9.8 is an excellent frame for XC, made of 6069-T6 custom hydro-formed SEVEN butted tube for high strength with minimal weight, 27.5” (S) size weighs only 1350g. Full inner cable routing, perfect headtube and geometry.

6061 and 7005 aluminum alloy are commonly used frame material, but having their down side, which is the weight of the frame.

Four versions are available, 27.5” and 29ER. Each has a special version of 9.8 PLUS.
PLUS means “Rear hube size compatible 142MMX12MM with 135MMX10MM’, make the strength enhanced, NOT the tire bigger.

Painting in 4colors.
TECHNICAL SPECIFICATION
Model: KING 9.8  27.5 or29er
Tubes: AL6069-T6 aluminium frame construction
Cable routing: internal or external cable routing option
Head tube: semi-integrated tapered ZS44/ZS56, head tube length 110mm (4.3")
Rear hub: rear hub 135mmx10mm
BB: threaded 68mm
Seat post/clamp: 30.9mm / 34.9mm
Max tire:  27.5X2.35  29ERX2.35
Weight:1350g
Size: s(16) M(17.5)L(18.5)
